System Features:
Dual Channel (A/B) Power Amplifier
8000 Watt Maximum Power Output
Integrated Digital SMT Technology
Stereo, Bridge & Parallel Mode Configurable
Built-in Variable Speed Cooling Fan
Dual Balanced XLR Input Connector Jacks
Dual 1/4'' Input Connector Jacks
Amp Limiter & Ground/Lift Switches
Dual Channel (A/B) SpeakON Connector Output Jacks
Single (Mono-Bridge) SpeakON Connector Output Jack
Speaker Terminal Binding Post / Banana Plug (A/B) Connector Output Jacks
Front Facing Control Center & Digital LCD Display
LED Indicator Lights - Protect, Clip, Signal Level
Independent Channel Rotary Knob Volume Controls
Loaded Select Button Switch: 4 Ohm/8 Ohm
Built-in Over-Current, Overheat & Cut-Wave Protection
Soft Start Limiter & DC Protect
Sensitivity Selector Switch
High Performance Ring Transformer
Heavy Duty Aluminum Heatsink
Includes AC Power Cable
Technical Specs:
Maximum Power Output: 8000 Watt
4000 Watt x 2 @ 2 Ohm
2000 Watt x 2 @ 4 Ohm
1000 Watt x 2 @ 8 Ohm
S/N Ratio: >110dB (Full Power @ 4 Ω)
Crosstalk: >80dB (Full Power @ 4 Ω)
Damping Factor: >600 (1kHz @ 4 Ω)
T.H.D. +N: <0.01% (Rated Power, 4 Ω/1kHz)
Frequency Response: 10Hz-50KHz, -1.5dB
Input Impedance: 10kΩ Unbalanced, 20kΩ Balanced
Sensitivity Switch Adjustable: 0.775V, 1.0V, 1.40V
Slew Rate: >65V/us
Idle Current Draw: 1.4A, 120V
LED Indicator Level Range: -30dB, -20dB, to -10dB
Power Supply: 110V, 50Hz
Dimensions (L x W x H): 18.9'' x 16.1'' x 3.5''
Sold as: UnitWeight: 34.07 lbs.
|
